Product Details
1.Up and down running using the step motor driving the ball screw, precision is up to 0.1mm, welding depth is accurate.
2.Up&down speed and the welding angle are adjustable,which decrease the surface tension, fulfill the technique requirement.
3.Automatic clear the solder oxide to the solder splash pot every work cycle,improve the welding quality.
4.Welding time, 1s-10s can be adjustable.
5.Soldering pot applies to the special thicky stainless steel, temperature controller applies to the K-thermocouple.
6.Suitable for the small quantity production.
7. With tri-color light, when over set temp. It will alarm and red light.
Our advantages:
1.We have a high tech team who can provide a series of professional technical support for our customers;
2.We are professional SMT&DIP machine factory in China for over 20 years;
3.Strict QC System. We will check two times with your orders. The first time is during mass production and the second time is prior to shipment. We will check each and test machine before shipment.
4.Competitive price. You can get a competitive price from here. Our price is factory price. Our purpose: customer oriented, quality first.
5.All machine size is customized,provide Non-standard service; We sincerely hope to work together with every clients, to build the long-term business and friendship. Believe in us, Believe in professional!
Specifications
| Model WS-310 | Dimensions 700*860*1320mm | Pot size 340*440*65mm |
| Pot capacity 80KGS | Start power 4.5KW | Constant temperature powe 0.8KW-1.2KW |
| Start control method By switch or foot switch | Heat-up time Approx.50 minutes | Power 1P AC 110V/220V 50/60HZ |
| Temp control method PID+SSR | PCB size 30mm*30mm–400mm*300mm | Weight Approx.110KGS |
Key Features
Economic type
High welding quality
Easy to operate
SMT&DIP machines factory in China! Good quality,Good serive, competitive price!
